WANCE TESTING EQUIPMENT FROM CHINA
WANCE is a high-tech enterprise integrated with design, production, sales, and services of testing machine and testing solution provision for mechanical test. The company headquarter is located in Shenzhen, with facilities both in Shenzhen and Shanghai. Taking great advantage of geography and human resources, WANCE attracts both the industry's top engineers and excellent management personnel from two big cities. Within decades, we strive to become the leading supplier in China and the top three worldwide.
We own the best technology and products in China, covering electromechanical universal testing machine, servo-hydraulic universal testing machine, servo-hydraulic compression testing machine, hydrostatic pressure testing machine, torsion testing machine, creep testing machine, pendulum impact testing machine, drop weight impact testing machine and other customized testing machines. Furthermore, our technology in instrumented impact transducers is leading in China.
Our products are widely used in R&D, quality analysis and quality control field, covering testing equipment, testing technology and transfer system of a quantitative value. Customers are widely distributed in aero-space, mechanical manufacture, vehicle, ship, construction, biological materials, colleges, universities, research institutes, national quality inspection institutes, export and import inspection institutes. We are keeping close cooperation with all factories, research institutes, and quality inspection organizations, and providing high quality products and services to satisfy customers' update demands.
From small melt flow indexer to big 100000J drop weight impact testing machine, WANCE relies on years of industrial expertise and creative technical team, delivering the greatest test support and confidence to customers across a wide range of fields. WANCE is dedicated to accelerating the innovation in test technology and test equipment, to supporting research projects, and to motivating enterprises in brand development and improvement.
UNIVERSAL TESTING MACHINE
New ETM series 2025
The newly developed ETM series of electromechanical universal testing machines provides higher testing speed, higher stiffness and higher accuracy testing control, which addresses the higher testing requirements in increasing testing demands in composite, high-strength steel and high-temperature alloy. Also, it suits the needs of standardized and routine testing, providing the user high quality at the most affordable price.
· STRONGER
Optimization design of crosshead and columns by finite element analysis; a large number of preload designs and assembly processes are used to optimize the various fits of ball screws and nuts, bearings and sensors, so as to reduce mechanical fit clearances, greatly improve the overall stiffness of the machine, and provide a guarantee for the test accuracy in the research of cutting-edge materials such as metals, rubbers, plastics and films. Single column frame is assembled with extra linear guide and dual-column frame is assembled with extra guidance columns, increasing the stiffness more.
- Ensure higher measurement accuracy, to determine elastic modulus, yield strength and tensile strength.
- Offer higher test stability, repeatability and reliability, which is the most important in the field of aerospace and research institutes.
- More versatile to test different materials, from soft rubber and plastic, to higher strength alloys and composites.
- Small vibration after specimen fracture, more durable to use.
· FASTER
The main machine transmission system of the ETM new-generation electronic universal testing machine adopts a servo direct-drive architecture, replacing traditional speed reducer transmission with a high-rigidity synchronous belt transmission system to achieve comprehensive performance improvements. Key advantages include:
Performance Enhancement
- Higher Test Speed & No-Load Return Speed: Significantly shortens test cycle time and improves efficiency.
- Faster Acceleration Response: Enables rapid adjustment of test conditions for faster testing requirements.
- Enhanced Operational Stability & Reliability: Reduces mechanical vibration and backlash, ensuring consistent and accurate measurement data.
Precision Improvement
The direct-drive structure eliminates energy loss and mechanical clearance caused by traditional reducers, thereby improving test precision and providing more reliable data support for material research (e.g., metals, composites, polymers).
Energy Efficiency Optimization
- Lower Energy Consumption: The servo direct-drive system operates with higher energy efficiency, reducing power loss compared to traditional transmission modes.
- High-Efficiency & Energy-Saving Technology: Ideal for high-strength, high-frequency test scenarios (e.g., quality control in manufacturing, material fatigue testing), balancing performance and sustainability.
- Technical Support for Cutting-Edge Applications
- The optimized transmission system meets the testing needs of advanced materials (e.g., ultra-high-strength alloys, flexible electronics, biodegradable plastics), providing a robust technical foundation for R&D and quality assurance in emerging industries.
- This upgrade not only enhances the machine’s core performance but also aligns with global trends toward energy efficiency and intelligent manufacturing, making it a versatile solution for modern material testing laboratories.
· SAFER
- Collision mitigation function offers sensitive detection of force change. It will stop automatically when force changing reaches the preset threshold. This function will reduce damages to load cell and specimens.
- Optional full-closed transparent shield with interlock function provides all-around protection for operators.
- Software can set the overload limit to prevent damage to load cell.
- Mechanical limit switch offers more protection.
SMARTER
Four primary colors that comply with the IEC 60073 standard allow visual interaction of the machine status by identifying different colors and modes.
· SIMPLER
TestPilot Universal test software with easy-to-understand icon makes it easier to train operators and configure test process, mostly improving test efficiency while minimizing costly errors.
- Quick test is available to start a test with simple crosshead control and simple calculation of maximum force and displacement.
- Preset testing methods: TestPilot includes a large quantity of pre-configured methods for some of the most commonly used ASTM, ISO and EN standards. Methods are specifically designed for different shape of specimens with different test accessories.
- Intuitive design of testing process: with step-by-step instructions, users can easily design a complete testing process with error-free.
- Integrated touch screen PC with intuitive test software facilitates test operation.
· Parameters
300kN with furnace
This 300kN electromechanical universal tensile testing machine is equipped with high temperature furnace. The temperature can reach 300~1100℃.
|
Model |
WHTF113A-B |
WHTF113A-C |
WHTF113A-B1 |
WHTF113A-C1 |
WHTF113A-B2 |
WHTF113A-C2 |
||
|
Type |
Standard |
Front open (for contact extensometer) |
Glass window (for video extensometer) |
|||||
|
Furnace structure |
Split type, 3-zone heating and spate control |
|||||||
|
Temperature range |
300℃~1100℃ |
|||||||
|
Uniform zone (mm) |
150 |
200 |
150 |
200 |
150 |
200 |
||
|
Inside dimension (mm) |
Φ110×330 |
Φ110×380 |
Ф110×330 |
Φ110×380 |
Φ110×330 |
Φ110×380 |
||
|
Outside dimension (mm) |
Φ350×450 |
Φ350×500 |
Φ350×450 |
Φ350×500 |
Φ350×450 |
Φ350×500 |
||
|
Front open |
No |
80mm(H)*20mm(W) |
110mm(H)*30mm(W) |
|||||
|
Heating element |
Ф 1.5mm Nichrome wire |
|||||||
|
Power supply |
3-phase, 380V±10%, 50Hz, 3.5kW |
|||||||
|
Cover temperature |
≤900℃, <65℃, 900℃~1100℃, <85℃ |
|||||||
|
Accuracy |
Temperature |
Fluctuation |
Uniformity |
|||||
|
300~600 |
±2 |
2 |
||||||
|
600~900 |
±3 |
3 |
||||||
|
900~1100 |
±4 |
4 |
||||||
50kN with chamber and video extensometer
This 50kN electromechanical universal tensile testing machine is equipped with liquid nitrogen cooling chamber and video extensometer. it enables to test at low and high temperature. Video extensometer offers accurate measurement specimen deformation at chamber.
|
Model |
EMC003A-1 |
EMC003A-2 |
|
Compatible with model |
ETM Series, Type C |
ETM Series, Type D |
|
Temperature range |
-70~+350℃ |
|
|
Wind circulation method |
centrifugal blower |
|
|
Temperature fluctuation |
≤±1℃ |
|
|
Temperature accuracy |
-70~200℃: ≤±2℃ 200~350℃: ≤±3.5℃ |
|
|
Temperature uniformity |
-70~200℃: ≤±2℃ 200~350℃: ≤±3.5℃ |
|
|
Temperature reading accuracy |
0.1℃ |
|
|
Heating time |
3℃/min |
|
|
Cooling time |
2℃/min |
|
|
Cooling method |
Liquid nitrogen |
|
|
Heat insulating material |
Aluminum silicate wool |
|
|
Inside dimension |
D240×W200×H600 mm |
D320×W300×H600 mm |
|
Outside dimension |
D900×W350×H760 mm |
D950×W450×H760 mm |
|
Weight |
100kg |
120kg |
|
Heating power |
1.6 kW |
2.4 kW |
|
Power supply |
1-phase AC220V±10%, 50Hz |
3-phase 5-line, AC380V±10%, 50Hz |
|
Maximum specimen length after break |
L=specimen clamp length between two grips +200 |
|
|
Working environment |
Temperature: +5℃~+35℃ Humidity:≤85% Atmospheric pressure: 86~106KPa |
|
600kN with chamber
600kN electromechanical tensile universal testing machine is equipped with hydraulic girp and environmental chamber.
Environmental chamber is compressor cooling, which provides temperature from -70℃ to +350℃. It allows the test at high and low temperature.
|
Model |
EMC003B-2 |
EMC004B-2 |
|
Compatible with model |
ETM-D |
|
|
Temperature range, ℃ |
-70~+350 |
-40~+350 |
|
Wind circulation method |
centrifugal blower |
|
|
Temperature fluctuation, ℃ |
≤±1 |
|
|
Temperature accuracy |
≤±2℃ (≤200℃), ≤±3.5℃ (>200℃) |
|
|
Temperature uniformity |
≤2℃ (≤200℃), ≤3.5℃ (>200℃) |
|
|
Temperature reading accuracy, ℃ |
≤±0.1℃ |
|
|
Heating time, ℃/min |
≥3 |
|
|
Cooling time, ℃/min |
≥2 |
|
|
Cooling method |
Compressor |
|
|
Inside dimension (DxWxH), mm |
320×300×600 |
|
|
Outside dimension (LxWxH), mm |
1900×710×930 |
|
|
Weight, kg |
350 |
330 |
|
Heating power consumption, kW |
5.3 |
4.9 |
|
Power supply |
3-phase, AC380V±10%, 50Hz |
|
|
Pull rod hole diameter, mm |
φ48 |
φ48 |
FORM+TEST PRUFSYSTEM TESTING EQUIPMENT
For more than 55 years we have been developing and producing testing machines in the Upper Swabian town of Riedlingen.
The once small business has developed over the years into an internationally recognized manufacturer for test machinery. The old firm of E. Seidner has been restructured by the management together with a committed team of employees into FORM+TEST a modern company for test systems. With state-of-the-art production techniques we can realise even the most exacting wishes and requirements which are put on high-quality test systems by science and industry.
Decades of experience in the rock testing field mean that FORM+TEST is a sought-after partner for geoscience. Our test solutions can determine typical geomechanical properties like uniaxial...
Compression Testing Machines
For standard-compliant compression strength testing of concrete cubes, concrete cylinders, concrete drill cores, natural stone samples, sand-lime bricks, masonry...
Universal Testing Machine - Dynamic
Ø Universal Testing Machine Type UP-E
Modular testing machine for demanding static and dynamic tests in research and development and quality control. The...
ROCK TEST
COMPRESSION TEST
UNIVERSAL TESTING MACHINE
HUMBOLDT TEST EQUIPMENT
Humboldt Mfg. Co., located in the United States, is a long-standing, leading manufacturer and supplier of testing equipment used for evaluating construction and civil engineering materials. Our equipment is used extensively throughout the world for testing soil, concrete, cement, asphalt and aggregate materials. This testing involves evaluations of materials, which are used in construction projects ranging from roads, bridges and tunnels to dams, earthworks, airports, railways, etc.
Humboldt equipment has been an integral partner in providing accurate and reliable testing results in a multitude of major projects worldwide while helping to deliver dependable infrastructure projects that adhere to project specifications. Users of our testing equipment include road contractors; governmental agencies; materials laboratories; cement plants; asphalt plants; universities; ready-mix concrete and precast producers, and consultants.
We will present complete information about Humboldt products soon....
SAND CONE TEST
Sand Cone Apparatus Set, 6.5" (165mm)
Sand Cone Apparatus Set, 6.5" (165mm)
ASTM D1556; AASHTO T191
The sand cone apparatus determines the in-place density of soils...
SAMPLE SPLITTER
Humboldt Sample Splitter Specifications
Model
Material Size (max.)
Chutes Number Width
Hopper L x W
inches (mm)
Pans (incl.)
Ship...
MIXING
Mortar Mixer, 5L (5.3qt)
ASTM C305; AASHTO T162; EN 196 DIN 1164; BS 3892; ISO 679
Two-speed mixer designed to mix cement mor- tars and pastes. Mixer provides manually-con- trolled...
CONCRETE AIR METER
Humboldt Concrete Air Meter
ASTM C231, AASHTO T152
The H-2783A air meter, which exceeds ASTM requirements, features the Humboldt, all-brass super pump, the most reliable and...
ASPHALT BINDER TESTING-VDO
Vacuum Degassing Oven (VDO Touch)
ASTM D6521; AASHTO R28-06: EN 14769
The vacuum degassing oven (VDO touch) is used to precisely and accurately degas pressure-aged...
THERMOMETER DIGITAL
Thermometer, High-Precision, Calibration
The HT-4795 precision hand-held thermometer is a 2-channel instrument that has a resolution of 0 001°C with a system accuracy of ± 0...
HUMBOLDT SOIL
HUMBOLDT AGGREGATE
HUMBOLDT CEMENT
HUMBOLDT CONCRETE
HUMBOLDT ASPHALT
HUMBOLDT LABORATORY
UTEST MATERIAL TESTING EQUIPMENT
UTEST adalah Produsen peralatan pengujian yang berlokasi di Turkey, UTEST memproduksi berbagai Alat pengujian Teknik Sipil, Batuan dan Pertambangan dengan Teknologi yang mutakhir. Untuk informasi lengkap silahkan klik salah satu menu di bawah ini :
UTEST SOIL TESTING
Water Level Indicator Product Code UTS-0050 Water Level Indicator 50 m Cable Length UTS-0052 Water Level...
UTEST AGGREGATE
1. Fully-Automated Sheartrac III System Product Code ShearTrac III The ShearTrac IIITM system is capable of performing the consolidation and...
UTEST CEMENT TESTING
1. Cement Samplers Product Code UTCM-0001 Packaged Cement Tube Sampler, Ø38x580 mm UTCM-0002 Bulk Cement Sampler,...
UTEST CONCRETE TESTING
1. ASTM & AASTHO - Automatic Compression Testing Machines for Cylinders Contact Us Request Catalog Product...
UTEST ASPHALT TESTING
1. Reflux Extraction Test Set Contact Us Request Catalog Product Code UTAS-0013 Reflux Extraction Test Set 1000 g, 220-240 V...
